Overview

 * Commercial Grade Kawasaki FT Engine - With Vortical Air Filtration assists with cleaning debris that extends engine life
 * Premium Seat - High-back seat with suspension to shield the operator from bumps & EVC cushion to take pressure off tailbone & lower back
 * BigBite Rear Tires - For smooth ride & enhanced traction
 * Foot Operated Deck Lift - Easily adjust the deck height between 1.5" - 4.5" with your foot
 * Easy Serviceability - Flip-up seat pan, removeable floor pan, & tooless removable pulley covers makes maintenance easy & simple
 * Fabricated Frame for Durability - 1.5" x 3.0" steel frame making it one of the toughest & most durable in its class
 * Welded Steel Deck - Durable 10 ga. welded fabricated steel
 * SmoothTrak Steering - Precision control to help trim & maneuver easily around obstacles. You will fully understand SmoothTrak steering when you drive ours and then drive theirs
 * Serviceable Commercial Grade Transmission - Hydro-Gear ZT-3200
 * Limited 4 Year/750 Hour Warranty

Specifications
Deck Size 48" 48" Rear Discharge 54" 54" Rear Discharge 60" 54" 60"
Availability OUT OF STOCK OUT OF STOCK In Stock OUT OF STOCK In Stock OUT OF STOCK OUT OF STOCK
Price $9,360 $9,588 $9,588 $9,930 $9,930 $9,702 $9,702
Engine Manufacturer Kawasaki Kawasaki Kawasaki Kawasaki Kawasaki Kohler Kohler
Engine HP 22 HP - FT691 22 HP - FT691 22 HP - FT691 22 HP - FT691 24 HP - FT730 27 HP - 7500 EFI 27 HP - 7500 EFI
Engine Displacement 726 cc 726 cc 726 cc 726 cc 726 cc 747 cc 747 cc
Drive System Type Dual Hydrostatic Dual Hydrostatic Dual Hydrostatic Dual Hydrostatic Dual Hydrostatic Dual Hydrostatic Dual Hydrostatic
Transmission Hydro-Gear ZT3200 Hydro-Gear ZT3200 Hydro-Gear ZT3200 Hydro-Gear ZT3200 Hydro-Gear ZT3200 Hydro-Gear ZT3200 Hydro-Gear ZT3200
Speed Up to 8 MPH Up to 8 MPH Up to 8 MPH Up to 8 MPH Up to 8 MPH Up to 8 MPH Up to 8 MPH
Parking Brake Patented automatic Patented automatic Patented automatic Patented automatic Patented automatic Patented automatic Patented automatic
Cutting Height 1.5" - 4.5" 1.5" - 4.5" 1.5" - 4.5" 1.5" - 4.5" 1.5" - 4.5" 1.5" - 4.5" 1.5" - 4.5"
Deck Lift Foot Operated Foot Operated Foot Operated Foot Operated Foot Operated Foot Operated Foot Operated
Deck Depth 5.0" 5.0" 5.0" 5.0" 5.0" 5.0" 5.0"
Blades 3 3 3 3 3 3 3
Blade Length 16.50" 16.50" 18.50" 18.50" 20.50" 18.50" 20.50"
Blade Tip Speed 18,600 18,600 18,900 18,900 18,400 18,900 18,400
Deck Spindles Aluminum with 1" shafts & sealed ball bearings Aluminum with 1" shafts & sealed ball bearings Aluminum with 1" shafts & sealed ball bearings Aluminum with 1" shafts & sealed ball bearings Aluminum with 1" shafts & sealed ball bearings Aluminum with 1" shafts & sealed ball bearings Aluminum with 1" shafts & sealed ball bearings
Deck Drive Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch Electric PTO clutch
Deck Construction Fabricated 10 ga. steel Fabricated 10 ga. steel Fabricated 10 ga. steel Fabricated 10 ga. steel Fabricated 10 ga. steel Fabricated 10 ga. steel Fabricated 10 ga. steel
Deck Spindle Mounts Reinforced 11 ga. steel Reinforced 11 ga. steel Reinforced 11 ga. steel Reinforced 11 ga. steel Reinforced 11 ga. steel Reinforced 11 ga. steel Reinforced 11 ga. steel
Impact/Trim Areas 11 ga. formed channel w/ rolled edge 11 ga. formed channel w/ rolled edge 11 ga. formed channel w/ rolled edge 11 ga. formed channel w/ rolled edge 11 ga. formed channel w/ rolled edge 11 ga. formed channel w/ rolled edge 11 ga. formed channel w/ rolled edge
Frame 1.5" x 3" steel tubing 1.5" x 3" steel tubing 1.5" x 3" steel tubing 1.5" x 3" steel tubing 1.5" x 3" steel tubing 1.5" x 3" steel tubing 1.5" x 3" steel tubing
Front Axle Fabricated with sealed ball bearings Fabricated with sealed ball bearings Fabricated with sealed ball bearings Fabricated with sealed ball bearings Fabricated with sealed ball bearings Fabricated with sealed ball bearings Fabricated with sealed ball bearings
Front Caster Wheels Heavy duty ball bearings, greasable Heavy duty ball bearings, greasable Heavy duty ball bearings, greasable Heavy duty ball bearings, greasable Heavy duty ball bearings, greasable Heavy duty ball bearings, greasable Heavy duty ball bearings, greasable
Front Caster Forks Fabricated 3/8" steel Fabricated 3/8" steel Fabricated 3/8" steel Fabricated 3/8" steel Fabricated 3/8" steel Fabricated 3/8" steel Fabricated 3/8" steel
Seat High-back suspension seat High-back suspension seat High-back suspension seat High-back suspension seat High-back suspension seat High-back suspension seat High-back suspension seat
Fuel Capacity 5 gallons 5 gallons 5 gallons 5 gallons 5 gallons 5 gallons 5 gallons
Cupholder Yes Yes Yes Yes Yes Yes Yes
Front Tire 13 x 5 - 6 13 x 5 - 6 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6 13 x 6.5 - 6
Drive Tire 23 x 9.5 - 10 Big Bite 23 x 9.5 - 10 Big Bite 23 11 - 10 Big Bite 23 11 - 10 Big Bite 23 11 - 10 Big Bite 23 11 - 10 Big Bite 23 11 - 10 Big Bite
(continued) Deck Size 48" 48" Rear Discharge 54" 54" Rear Discharge 60" 54" 60"
Weight 835 lbs 840 lbs 845 lbs 860 lbs 865 lbs 845 lbs 865 lbs
Height 48.9" / 68.7" w/ ROPS up 48.9" / 68.7" w/ ROPS up 48.9" / 68.7" w/ ROPS up 48.9" / 68.7" w/ ROPS up 48.9" / 68.7" w/ ROPS up 48.9" / 68.7" w/ ROPS up 48.9" / 68.7" w/ ROPS up
Length 773.6" 773.6" 74.42" 74.42" 75.92" 74.42" 75.92"
Width w/Chute Up 49.1" 48.85" 55.1" 54.85" 61.1" 55.1" 61.1"
Tire Width 47" 47" 52" 52" 52" 52" 52"
Trim Side 1" 1" 3" 3" 6" 3" 6"
Acres per Hour (80% efficiency) 3.10 3.10 3.48 3.48 3.88 3.48 3.88
Warranty 4 Year / 750 Hour 4 Year / 750 Hour 4 Year / 750 Hour 4 Year / 750 Hour 4 Year / 750 Hour 4 Year / 750 Hour 4 Year / 750 Hour
